Measure, record, and view four channels of thermocouple temperature data with this open source Arduino™-compatible data logger.
The Pax Instruments T400 datalogger is an open source four-channel thermocouple temperature datalogger based on the Arduino™ Leonardo platform. It is ready to use out of the box with the features you want most. Measurements can be logged to MicoSD card, printed to serial port, and graphed. The T400 is a great tool for anything from live thermal process monitoring in the lab to long-term environmental data collection in the field.
The Pax Instruments T400 datalogger is designed to be out of the box ready for professionals and hobbyists alike. If you need a temperature datalogger that works every time, this is the device for you.
Open source spirit
The hardware and software design files are available to you at no cost to use, modify, or redistribute. This allows you and others to extend the devices capabilities or tailor it to your specific application.
Arduino™-compatible hardware means while hacking on the platform you will be able leverage the work of others while sharing your own work with large community of hackers and makers. Sharing is caring.
Readings can be saved to a microSD card in standard CSV format for processing in Microsoft Excel, LibreOffice, or your favorite data analysis tool.
USB serial port
Readings can captured live via the USB serial port. This is perfect for live process monitoring in lab experiments or connecting to an internet-enabled device.
Thermocouples connect via standard mini thermocouple connectors. The T400 is compatible with a wide variety of K-type thermocouple sensor types from stainless steel probes to rolling surface-contact sensors.
